23GYP042 Coursework 2, Practical 1: Drought-induced changes to vegetation
In this exercise you will work to quantify (calculate) the impact of the 2022 drought through changes that occurred in the state of the vegetation at different study sites, as detected by satellite observations.
In one aspect of the Individual Coursework you extracted an indication of the amount of vegetation at each of your dust source points by sampling an NDVI dataset (Normalised Difference Vegetation Index). The NDVI is an index (between 0 and 1), and while its value is not a direct measurement of vegetation, it can be thought of as showing how green or healthy plant leaves are. NDVI is widely used for large-scale studies of vegetation change.
In the Individual Coursework you manually used a point shapefile to sample a single NDVI file which represented the state of the vegetation in the Texas region on one date.
Part 1: Automatic processing of multiple MODIS data files
To look at NDVI change over time we need to analyse multiple (perhaps 10s or 100s) of NDVI data files, but it is impractical for us to do this many times in a very labour intensive, manual way. Here, you will use Python, a computer script-based technique which is a way to automatically and repeat-run helpful GIS tools. The tools you will run in Python are ArcGIS tools you are already familiar with manually from the Texas study, such as ‘Zonal Statistics as Table’ .
• Practicing with the Python script in our local region: Leicestershire
A) Set up a new Cwk2 folder in your OneDrive.
B) From Learn, download the NDVI_Part1 folder and place it into Cwk2. In Part1, there are sixteen MODIS NDVI .tif files inside 2022_NDVI_tifs, a shapefile of the Leicestershire county boundary, and a Python script (23GYP042_batch_raster_zonal_stats.py)
The sixteen files here provide the NDVI values at 16-day intervals over the period 18th February (Day of Year 049) to 16th October (DoY 289) for the whole UK. The ‘DoY’ number is shown as part of the filename alongside the year, as in _doy2022049 for the first file.
C) Right click on the 23GYP042_batch_raster_zonal_stats.py script and select “Edit with IDLE”
D) When the script window opens, use the square icon at the top-right to maximise the window.
E) Don’t be put-off by the code! With a few edits, this script will soon be working for you.
In the Python code, all the red text is comment text which the program will not read. This is text written to help users understand the code, and comment lines begin with # symbol.
Because we only want to give you a working example of Python, rest assured you will only need to make a few straightforward edits to tailor the code to work on your data.
The comment text highlights four STEPS where you will need to make certain changes.
STEP 1: Here you will need to edit the green text to ensure the written file address points to the precise location of your 2022_NDVI_tifs folder is on your OneDrive.
Note, everyone’s downloaded folder will be in a different location on their OneDrive.
F) To help you, use File Explorer to navigate to where your 2022_NDVI_tifs folder is saved. When you are in the folder (see below), right-click on the 2022_NDVI_tifs folder on the folder address line (see big arrow) and select “Copy address as text” .
G) Go back to the Python code, and in the line below the green text of STEP 1, paste the address text where it says #PASTE FOLDER ADDRESS HERE>
Now carefully edit the green text in the Python script at STEP 1 to match the 2022 folder containing the NDVI data.
The address you enter will need to be exactly correct (e.g. ensure the ‘gy’ name of OneDrive is correct, and use \\ ), but we will test your accuracy later.
H) Next, to complete STEP 2, first you need to create a new empty folder inside your 2022_NDVI_tifsfolder and name the new folder 2022_out_tables
Use the process in F again to edit the STEP 2 green text to state the address to your new
2022_out_tables
I) For STEP 3, you need to edit the address text to point to your Leicestershire_county.shp shapefile, which defines the area to be sampled.
J) For STEP 4, follow the instructions in the red comments to edit the green text in the outTable line.
K) After STEP 4, you are ready to run the script via the Run menu (Run Module), or press the F5 key (and OK to save).
Progress will be shown in the Python Shell window. Watch for the number of rasters being printed on screen, plus, all the raster names in a long list.
You will see the following when the script has finished running.
Note: Problems CAN occur with scripts and there is a strong chance your script may need
some de-bugging. The syntax of the script has to be exact. Once it is working, however, this script is very convenient as it allows large amounts of data to be analysed quickly, and when set up correctly once, will always run reliably for you.
The output will be 16 tables generated into your 2022_out_tables folder. The last stage is that these individual outputted tables now need to be merged into a single table.
In ArcGIS, run the Merge tool manually from the Data Management >> General toolbox.
Make sure you add all the individual tables and name a sensible output table such as
2022_NDVI_Leics_all
Make sure to specify the filetype as "Table" in the "Save as type" dialog, and a .dbf ending to the output table filename is required.
L) When the merge is complete, the resulting _all.dbf table can be opened in Excel as a dBase (.dbf) file. Open Excel and browse to the _all.dbf file … make sure you are looking for files of dBase type (not Excel files). As soon as you open the file, ‘Save As’ the file immediately to put it into a normal Excel .xlsx form.
M) Check some of the mean NDVI numbers you see with your group members to see if your values are the same as theirs. They should be! You can also create a quick Excel plot to see how the mean NDVI changed through the year in Leicestershire.
Part 2: Individual study area selection
In the above example we examined NDVI change during part of 2022 in Leicestershire. For the group project, each group member will have the responsibility of looking at the NDVI change experienced within a different vegetation study area inside the UK climate district your group has been assigned.
Looking at column 1 in the table below, you can see there are four different types of vegetation study area for this project. In terms of the analysis, there is no difference who selects which type of study area so in your group, agree on one type of study area to each group member. (Groups with three people only need to pick any three of the four vegetation sites). Note the person responsible in column 2 below.
1. Type of vegetation study area |
2. Group member responsible |
3. Shapefile name |
4. Name of chosen vegetation study area |
County |
|
Veg Areas counties.shp |
|
National Park or Area of Natural Beauty (AONB) |
|
Veg_Areas_NationalParks.shp Veg_Areas_AONB.shp |
|
National Trust land |
|
Veg_Areas_NT_Land_open.shp Veg_Areas_NT_Land_limited.shp |
|
Ancient Woodland site |
|
Veg_Areas_Ancient_Woodland.shp |
|
A) Download the NDVI_Part2 files folder from Learn, and from inside it, open the Met_Office_Climate_Districts shapefile in ArcGIS.
Open the attribute table and select your group’s climate district, then right click on the climate districts shapefile in the Table of Content window and Data >> Export Data with a sensible .shp name for your district.
B) Next from NDVI_Part2 open the Veg_Areas shapefile for the vegetation study area you have responsibility for (see column 3 in table above).
To use in the Python script, you need to isolate one polygon from your Veg_Areas shapefile. For some area types like County or National Parks, the choices will be limited.
For the Ancient Woodland shapefiles, use (menu) Selection >> Select by Location and use your group climate district to select only the polygons in your district and export these, to help narrow down your choice.
You can find information about any polygon (such as its name and some details) by using the Identify tool from the menu. At the top of the Identify box, make sure the “Identifying from:” is the Veg_Area shapefile you require. |
|
Take a minute or so here to choose your polygon. Any polygon will work, but ask the opinion of your team mates about the polygon you will select. You may want to add in (any) one of the 2022 NDVI .tif files to get a feel for the study area polygons’ size versus the spatial resolution of the NDVI data (250 m).
C) To select and export your chosen polygon, first right click on your Veg_Areas shapefile in the Table of Contents and >> Selection >> Make This The Only Selectable Layer.
Use the Selection tool icon from the menu to highlight the polygon, then right click on the shapefile name and export it, with a suitable new .shp name. This shapefile will be the one used in the Python code. |
Keep a record of the name of each person’s study site in column 4 of the table.
D) You can now adapt the Python script (at STEPS 2,3,4) and then run it again to swiftly quantify NDVI change in 2022 for your chosen vegetation study area.
Part 3: Comparing the NDVI change in 2022 to other years
Download NDVI_Part3 and you will see there are different years of NDVI data.
You will be able to use these other years to determine:
a. the difference in NDVI pattern between the 2022 drought summer versus 2021 (the year before)
b. the difference in NDVI pattern between the 2022 drought summer and a longer-term average made up of the average of three years (2005, 2010, 2015).
Again, only minor changes to STEPS 1 and 2 on the Python script need to be adjusted to run each different year and output the NDVI statistics.
Part 4: Calculation of NDVI from Landsat data
One of the benefits of using the pre-processed NDVI data products from MODIS (i.e. MOD13Q1) is that the NDVI values come pre-calculated for us. One of the disadvantages is that at 250 m pixel size, the data is spatially coarse.
In the first practical in Week 1, studying Etosha Pan in Namibia, you briefly looked at individual bands of satellite data. Each band represents the detection of electromagnetic radiation in a specific part of the spectrum, and NDVI is calculated by the simple processing of two bands, the Red and Near-Infrared (NIR) bands which interact differently with vegetation. To calculate NDVI we use the following formula:
NDVI = (BandNIR - BandRed) / (BandNIR + BandRed) (Eq. 1)
For the Landsat 8 and 9 satellites, which both carry the Operational Land Imager (OLI) sensor and are both currently active, NIR is Band 5 and Red is Band 4. So:
NDVI = (Band5 - Band4) / (Band5 + Band4) (Eq. 2)
For this Part, your group is tasked with calculating the NDVI from Landsat for one of your chosen study areas (table column 1). This will provide a higher spatial resolution assessment of NDVI and will allow you to tackle the question:
To what extent do NDVI estimates at different spatial resolutions (MODIS versus Landsat) produce different NDVI results?
Your first task as a group, is to decide on the single focus area you will pick. It could be the National Park, or the County, or the Ancient Woodlands that one of your group picked in Part 2.
As you will all use the same shapefile, the responsibility for each individual group member is to calculate the NDVI for a different date.
Use the EarthExplorer platform to search for Landsat 8 or 9 images between 16th February 2022 and 18th October 2022. (The guide for downloading from Earth Explorer was in the Week 2 practical handout, but we are seeking Landsat 8-9, not Landsat 4-5.) On the download, only Bands 4 and 5 are required (Bands 4,3,2 are required for true colour, if of interest).
• Each group member obtains a different date from the period
Group member |
Landsat date |
|
|
|
|
|
|
|
|
|
|
• Use the Raster Calculator tool to calculate NDVI via Equation 2
• Use the Extract by Mask tool to cut out the NDVI image according to the study shapefile you are using
P.S. For Part 1, here is a link to a helpful calendar for converting DoY to actual date.
https://landweb.modaps.eosdis.nasa.gov/browse/calendar.html
