How to Play Battleship

Please take a look at these rules even if you have played Battleship before in your life. Remember this is a Human vs. Computer version.

The computer places the ten ships on the ocean in such a way that no ships are immediately    adjacent to each other, either horizontally, vertically, or diagonally. Take a look at the following diagrams for examples of legal and illegal placements:

The human player does not know where the ships are. The initial display of the ocean printed to the console therefore shows a 10 by 10 array of ‘.‘ (see the description of the Ocean class’ print() method below for more information on what subsequent ocean displays will look  like).

The human player tries to hit the ships, by indicating a specific row and column number (r,c). The computer responds with one bit of information saying, “ hit” or “ miss”.

When a ship is hit but not sunk, the program does not provide any information about what kind of a ship was hit. However, when a ship is hit and sinks, the program prints out a message “You just sank a ship - (type).” After each shot, the computer re-displays the ocean with the new information.

A ship is “sunk” when every square of the ship has been hit. Thus, it takes four hits (in four     different places) to sink a battleship, three to sink a cruiser, two for a destroyer, and one for a submarine.

The object is to sink the fleet with as few shots as possible; the best possible score would be

20 (lower scores are better.) When all ships have been sunk, the program prints out a message that the game is over, and tells how many shots were required.

Details of Implementation

Name your project Battleship, and your package battleship.

Your program should have the following 8 classes:

● class BattleshipGame

o    This is the “ main” class, containing the main method, which starts by creating an instance of Ocean

● class Ocean

o    This contains a 10x10 array of Ships, representing an “ocean”, and some methods to manipulate it

● abstract class Ship

o   This abstract class describes the characteristics common to all ships

o     It has subclasses:

.     class Battleship extends Ship

●    Describes a ship of length 4

.     class Cruiser extends Ship

●    Describes a ship of length 3

.     class Destroyer extends Ship

●    Describes a ship of length 2

.     class Submarine extends Ship

●    Describes a ship of length 1

.     class EmptySea extends Ship

●    Describes a part of the ocean that doesn’t have a ship in it. (It

seems silly to have the lack of a ship be a type of ship, but this is a trick that simplifies a lot of things. This way, every location in the   ocean contains a “ship” of some kind.)

Abstract class Ship

The abstract Ship class has the instance variables below.

Note: Fields should be declared private unless there is a good reason for not doing so.  This is known as “encapsulation”, which is the process of making the fields in a class private and

providing access to the fields via public methods (e.g. getters and setters).

● private int bowRow

o   The row that contains the bow (front part of the ship)

● private int bowColumn

o    The column that contains the bow (front part of the ship)

● private int length

o   The length of the ship

● private boolean horizontal

o     A boolean that represents whether the ship is going to be placed horizontally or

vertically

● private boolean [] hit

o     An array of booleans that indicate whether that part of the ship has been hit or not

The default constructor for the Ship class is:

● public Ship(int length)

o     This constructor sets the length property of the particular ship and initializes the hit array based on that length

The methods in the Ship class are the following:

Getters

● public int getLength()

o    Returns the ship length

● public int getBowRow ()

o    Returns the row corresponding to the position of the bow

● public int getBowColumn ()

o    Returns the bow column location

● public boolean [] getHit()

o    Returns the hit array

● public boolean isHorizontal()

o    Returns whether the ship is horizontal or not

Setters

● public void setBowRow (int row)

o    Sets the value of bowRow

● public void setBowColumn (int column)

o    Sets the value of bowColumn

● public void setHorizontal(boolean horizontal)

o    Sets the value of the instance variable horizontal

Abstract Methods

● public abstract String getShipType ()

o     Returns the type of ship as a String.  Every specific type of Ship (e.g.

BattleShip, Cruiser, etc.) has to override and implement this method and return the corresponding ship type.

Other Methods

●   boolean okTo PlaceShipAt(int row, int column, boolean horizontal, Ocean ocean)

o     Based on the given row, column, and orientation, returns true if it is okay to put a   ship of this length with its bow in this location; false otherwise. The ship must not overlap another ship, or touch another ship (vertically, horizontally, or diagonally),  and it must not ”stick out” beyond the array. Does not actually change either the

ship or the Ocean - it just says if it is legal to do so.

●   void placeShipAt(int row, int column, boolean horizontal, Ocean ocean)

o     “ Puts” the ship in the ocean. This involves giving values to the bowRow,

bowColumn, and horizontal instance variables in the ship, and it also involves

putting a reference to the ship in each of 1 or more locations (up to 4) in the ships

array in the Ocean object. (Note: This will be as many as four identical references; you can’t refer to a ” part” of a ship, only to the whole ship.)

o     For placement consistency (although it doesn’t really affect how you play the

game), let’s agree that horizontal ships face East (bow at right end) and vertical ships face South (bow at bottom end).

.    This means, if you place a horizontal battleship at location (9, 8) in the ocean, the bow is at location (9, 8) and the rest of the ship occupies

locations: (9, 7), (9, 6), (9, 5).

.    If you place a vertical cruiser at location (4, 0) in the ocean, the bow is at

location (4, 0) and the rest of the ship occupies locations: (3, 0), (2, 0).

● boolean shootAt(int row, int column)

o    If a part of the ship occupies the given row and column, and the ship hasn’t been sunk, mark that part of the ship as “ hit” (in the hit array, index 0 indicates the

bow) and return true; otherwise return false.

● boolean isSunk()

o    Return true if every part of the ship has been hit, false otherwise

● @Override

public String to String()

o     Returns a single-character String to use in the Ocean’s print method. This method should return ”s” if the ship has been sunk and ”x” if it has not been sunk. This

method can be used to print out locations in the ocean that have been shot at; it

should not be used to print locations that have not been shot at. Since to String behaves exactly the same for all ship types, it is placed here in the Ship class.

Class ShipTest

This is the JUnit test class for the Ship class. The ShipTest.java file we have provided contains SOME of the unit tests for this assignment.  There will be more tests for the Ship class that  we will be running your program against.  Import ShipTest.java into your Java project and

implement enough code in the methods in your program to pass all tests.

Generate additional scenarios and add test cases to each test method.  You should have a total of at least 3 distinct scenarios and valid test cases per method (including the ones provided).    For example, one scenario could be, you create and place a battleship in a particular location in the ocean by calling its placeShipAt method.  Then you create a destroyer and see if it can be    placed in a particular location by calling its okToPlaceShipAt method.  If so, you place it.  Then

you create a cruiser and see if it can be placed in a particular location by calling its okToPlaceShipAt method.  If so, you place it.

Test every non-private method in the Ship class. (Unfortunately, you can’t test methods that are private because they are inaccessible outside of the class.)

Also test the methods in each subclass of Ship. You can test the Ship method and its subclasses in the same file.

You must include comments to explain your different testing scenarios.

Class BattleshipGame

The BattleshipGame class is the “ main” class -- that is, it contains a main method. In this

class you will set up the game; accept ”shots” from the user; display the results; and print final  scores. All input/output is done here (although some of it is done by calling a print() method in the Ocean class.) All computation will be done in the Ocean class and the various Ship classes.

To aid the user, row numbers should be displayed along the left edge of the array, and column numbers should be displayed along the top. Numbers should be 0 to 9, not 1 to 10. The top

left corner square should be 0, 0. Use different characters to indicate locations that contain a hit, locations that contain a miss, and locations that have never been fired upon.

For example, here’s a display of the ocean when the program first launches, and no shots have been fired.

Use various sensible methods. Don’t cram everything into one or two methods, but try to divide up the work into sensible parts with reasonable names.

Extending abstract class Ship

Use the abstract Ship class as a parent class for every single ship type. Create the following classes and keep each class in a separate file.

● class Battleship extends Ship

● class Cruiser extends Ship

● class Destroyer extends Ship

● class Submarine extends Ship

Each of these classes has a zero-argument public constructor, the purpose of which is to set the length variable to the correct value.  From each constructor, call the constructor in the

super class with the appropriate hard-coded length value for each ship.  Note: You can store the hard-coded int values in static final variables.

Aside from the constructor you have to override this method:

● @Override

public String getShipType ()

o     Returns one of the strings “battleship”, “ cruiser”, “destroyer”, or

“ submarine”, as appropriate.  Again, these types of hard-coded string values are good candidates for static final variables.

o    This method can be useful for identifying what type of ship you are dealing with, at any given point in time, and eliminates the need to use instanceof

Class EmptySea extends Ship

You may wonder why “EmptySea” is a type of Ship. The answer is that the Ocean

contains a Ship array, every location of which is (or can be) a reference to some Ship. If a     particular location is empty, the obvious thing to do is to put a null in that location. But this

obvious approach has the problem that, every time we look at some location in the array, we’d have to check if it is null. By putting a non-null value in empty locations, denoting the

absence of a ship, we can save all that null checking.

The constructor for the EmptySea class is:

● public EmptySea ()

o   This zero-argument constructor sets the length variable to 1 by calling the constructor in the super class

The methods in the EmptySea class are the following:

● @Override

boolean shootAt(int row, int column)

o    This method overrides shootAt(int row, int column) that is inherited from Ship, and always returns false to indicate that nothing was hit

● @Override

boolean isSunk()

o    This method overrides isSunk() that is inherited from Ship, and always returns false to indicate that you didn’t sink anything

● @Override

public String to String()

o     Returns the single-character “-“ String to use in the Ocean’s print method.

(Note, this is the character to be displayed if a shot has been fired, but nothing has been hit.)

● @Override

public String getShipType ()

o    This method just returns the string “empty”

Class Ocean

Instance variables

● private Ship[][]ships = new Ship[10][10]

o    Used to quickly determine which ship is in any given location

● private int shots Fired

o   The total number of shots fired by the user

● private int h itCount

o   The number of times a shot hit a ship. If the user shoots the same part of a ship more than once, every hit is counted, even though additional “ hits” don’t do the user any good.

● private int ships Sunk

o   The number of ships sunk ( 10 ships in all)

Constructor

● public Ocean ()

o     Creates an ”empty” ocean (and fills the ships array with  EmptySea objects). You could create a private helper method to do this.

o    Also initializes any game variables, such as how many shots have been fired.

Methods

● void placeAllShipsRandomly()

o     Place all ten ships randomly on the (initially empty) ocean. Place larger ships    before smaller ones, or you may end up with no legal place to put a large ship.  You will want to use the Random class in the java.util package, so look that up in the Java API.

o    To help you write the code for this method, reference the printWithShips ()

method below.  It will allow you to see where ships are actually being placed in the Ocean while you are writing and debugging your program.

● boolean isOccupied(int row, int column)

o    Returns true if the given location contains a ship, false if it does not

● boolean shootAt(int row, int column)

o     Returns true if the given location contains a ” real” ship, still afloat, (not an

EmptySea), false if it does not. In addition, this method updates the number of shots that have been fired, and the number of hits.

o     Note: If a location contains a “ real” ship, shootAt should return true every time the user shoots at that same location. Once a ship has been ”sunk”, additional

shots at its location should return false.

● int getShots Fired()

o    Returns the number of shots fired (in the game)

● int getHitCount()

o    Returns the number of hits recorded (in the game). All hits are counted, not just

the first time a given square is hit.

● int getShips Sunk()

o    Returns the number of ships sunk (in the game)

● boolean isGameOver ()

o    Returns true if all ships have been sunk, otherwise false

● Ship[][] getShipArray()

o    Returns the 10x10 array of Ships. The methods in the Ship class that take an Ocean parameter need to be able to look at the contents of this array; the

placeShipAt() method even needs to modify it. While it is undesirable to

allow methods in one class to directly access instance variables in another class, sometimes there is just no good alternative.

● void print()

o    Prints the Ocean. To aid the user, row numbers should be displayed along the left edge of the array, and column numbers should be displayed along the top. Numbers should be 0 to 9, not 1 to 10.

o    The top left corner square should be 0, 0.

o    ‘x’: Use ‘x’ to indicate a location that you have fired upon and hit a (real) ship. (reference the description of toString in the Ship class)

o ‘-’: Use ‘-’ to indicate a location that you have fired upon and found nothing there.  (reference the description of toString in the EmptySea class)

o     ‘ s’ : Use ‘s’ to indicate a location containing a sunken ship.  (reference the description of toString in the Ship class)

o ‘.’: and use ‘ . ’ (a period) to indicate a location that you have never fired upon

o    This is the only method in the Ocean class that does any input/output, and it is never called from within the Ocean class, only from the BattleshipGame

class.

For example, here’s a display of the ocean after 2 shots have missed.

And here’s a display of the ocean after 2 shots have missed, and 1 has hit a (real) ship.

To further help you understand how to write the code for this method, here’s the (high-level) logic for printing the ocean:

for each location in the 10 by 10 array (the “ocean”)

●    if the location contains a ship that is sunk or if the location has been shot at, and was hit or nothing was found

○    print the ship itself -- this will call to String in the Ship class or any Ship subclass which has to String defined (i.e. EmptySea)

● otherwise print “.”

● void printWithShips ()

o     USED FOR DEBUGGING PURPOSES ONLY.

o    Like the  print() method, this method prints the Ocean with row numbers

displayed along the left edge of the array, and column numbers displayed along the top. Numbers should be 0 to 9, not 1 to 10.  The top left corner square

should be 0, 0.

o    Unlike the print() method, this method shows the location of the ships. This method can be used during development and debugging, to see where ships are actually being placed in the Ocean.  (The TAs may also use this

method when running your program and grading.)  It can be called from the BattleshipGame class, after creating the Ocean and placing ships in it.

o    Be sure to comment out any call to this method before actually playing the game and before submitting your Java project.

o ‘ b’: Use ‘ b’ to indicate a Battleship.

o    ‘c’: Use ‘c’ to indicate a Cruiser.

o ‘d’: Use ‘d ’ to indicate a Destroyer.

o    ‘s’: Use ‘s’ to indicate a Submarine.

o ‘ ‘: Use ‘ ’ (single space) to indicate an EmptySea.

For example, here’s a display of the ocean after creating the Ocean, calling placeAllShipsRandomly, and then calling printWithShips.

You are welcome to write additional methods of your own. Additional methods should have

default access (accessible anywhere in the package) and be tested, if you think they have some usefulness outside of this class.  If you don’t think they have any use outside of this class, mark them as private.

Class OceanTest

This is the JUnit test class for the Ocean class. The OceanTest.java file we have provided

contains SOME of the unit tests for this assignment.  There will be more tests for the Ocean class that we will be running your program against.  Import OceanTest.java into your Java

project and implement enough code in the methods in your program to pass all tests.

Generate additional scenarios and add test cases to each test method.  You should have a total of at least 3 distinct scenarios and valid test cases per method (including the ones provided).    For example, a scenario could be, you create and place a submarine in a particular location in

the ocean by calling its placeShipAt method.  Then you check if a particular location in the

ocean is occupied by calling its isOccupied method.  Create and place another submarine in a particular location by calling its placeShipAt method.  Then check if another location in the

ocean is occupied by calling its isOccupied method.

Test every required method for Ocean, including the constructor, but not including the

print() method. If you create additional methods in the Ocean class, you must either make them private, or write tests for them.

Note: Two test methods have been completely implemented for you, meaning, no additional   test cases are required.  (Of course, you’ re welcome to add more!).  These are testEmptyOcean and testPlaceAllShipsRandomly.

testEmptyOcean tests if every location in an empty ocean is “empty”.  Since it’s the constructor in the Ocean class that is responsible for creating an ”empty” ocean (and filling the ships array with EmptySeas), the testEmptyOcean method can be considered the test method for the

Ocean class constructor.

testPlaceAllShipsRandomly tests that the correct number of each ship type is placed in the ocean after calling placeAllShipsRandomly.

You must include comments to explain your different testing scenarios.

What to Submit

Please submit all the Java classes in your Java project. Make sure to include everything in your “src” folder.

If you’ re working as part of a team, only one student from your team needs to submit the files.  Include the members of your team as part of the @author tag in the Javadocs for each class.  If Brandon was working with Sarah, their Javadocs and @author tag would look something like:

Evaluation

You will be graded out of 52 points:

● Style (8 pts total)

o   This includes, but is not limited to:

.    Adding Javadocs to every class, method, and variable, and comments to all non-trivial code.

.    Indenting properly (Cmd+i or Ctrl+i) and using { brackets } correctly in loops and conditionals

.    Naming additional variables and methods descriptively with camelCase

.    Removing unused variables and commented out code blocks/print statements used for debugging

● Game play (10 pts total)

o   This comes down to whether or not a TA can play your game. The interface

should be clear. If you have made some potentially unusual design choice, please make sure that you point that out very clearly. If you do not know what this

means, it might be worth asking on EdDiscussion or during office hours. If you followed all the instructions to the letter, you are fine.

● Unit testing (24 pts total)

o    Please make sure you pass the provided tests as well as your own additional unit tests (10 pts)

o    Passing our own unit tests (14 pts)
