ELEC 202
SPECIMEN PAPER
SECOND SEMESTER EXAMINATION
REPLACEMENTS 2019/20
COMMUNICATION SYSTEMS
1. a) The Internet backbone refers to one of the principal data routes between large, strategically interconnected networks and core routers on the Internet. It is a very high-speed data transmission line (typically a fiber optic trunk line) that provides networking facilities to Internet service providers all around the world.
Using your knowledge of communications, explain why the Internet backbone consists of cables rather than wireless connections. Use no more than 200 words.
b) An audio message of bandwidth B Hz is sampled at Fs Hz prior to digitisation, where Fs < 2B. In order to avoid aliasing effects, an anti- aliasing filter of cut-off frequency Fc Hz can be used, either
i) before the sampler, or
ii) after the sampler
Derive expressions for the fraction of the message bandwidth that can be successfully recovered following reconstruction in both cases above, and comment on the effect this filtering will have on the nature of the recovered audio. Illustrate your answer using spectral sketches.
c) Design suitable communication systems (including block diagrams, modulation schemes or formats, etc) for each of the following scenarios. Suggest suitable values for relevant parameters, as appropriate, such as carrier frequency, bandwidth, sampling rate, bit depth, etc. Use no more than 1 page.
i) An analogue talk radio station.
ii) An analogue television station.
iii) A fibre optic transmission system for telephone signals for a 20 storey apartment building.
iv) A home-made security camera system using a 4G smartphone.
d) Explain what is meant by ‘companding’, indicating where and why it is used. Suggest a suitable transformation function for use in companding, and illustrate its use with a suitable example. Do not exceed ½ a page.
Total 25
2. a) The output of an ultrasonic transducer is to be sampled at a rate of fs samples per second with a G Hz guard band between spectral replicas, and subsequently transmitted via cable using analogue PAM. Design a suitable communication system to achieve this, giving expressions for relevant parameters, and illustrating your design with a suitable block diagram. Use no more than ½ page.
b) Consider a time-division multiplex system with m signals, each bandlimited to B Hz and quantized using n bits. If the transmission system can support a maximum signal-to-noise ratio of R dB, derive an expression for the number (m) of users that can simultaneously share the channel?
Illustrate your findings with a suitable example scenario.
c) Show that the NBFM expression for a single tone message can be written as a scaled version of
cos ωc t − β sin ωc t ⋅ sin ωmt
Sketch the above signal in the time and frequency domains, and comment on the bandpass bandwidth.
d) Discuss 2 possible approaches for the demodulation of FM, illustrating and describing in as much detail as possible how each approach works. Use no more than 300 words and 1 page.
Total 25
3. a) Explain, in as much detail as possible, how the bandpass bandwidth of an FM signal can be estimated. Use no more than ½ a page.
b) Explain the structure and function of a coherent detector, and discuss the various ways in which coherent detectors can be used with different forms of modulation, including as much mathematical detail as possible. Do not exceed 1 page.
c) Explain what factors govern the maximum rate at which data can be communicated error-free across a channel and discuss some of the implications of this. Present your answer in as much detail as possible, using sketches and diagrams to help illustrate your point where relevant, and stating any assumptions made. Use no more than 200 words.
d) NASA’s New Horizon space probe has provided us with stunning high-resolution 4096-level grayscale images of, among other things, the surface of Pluto, a dwarf planet at the outer edge of our Solar System. The probe encountered Pluto at a distance of 4.6 billion km from Earth, fom where it transmitted a series of 312.5 kB images back to earth using binary PSK modulation with a carrier frequency of 8.438 GHz (NB a kB is a thousand bytes, and one byte is 8 bits). Due to the distance involved and the limited power on board, the data rate was limited to approximately 1 kbit/sec.
Estimate the time it would take between transmission (from the probe) and reception (on Earth) of a single such image, and hence estimate how many images could be received during a month of constant transmission, stating any assumptions made.
Total 25
4. a) For the binary bit stream segment {… 0, 0, 0, 1, 1, 0, 1, 1 …} sketch the corresponding bandpass signals using the following modulation formats:
i) BFSK
ii) BPSK
iii) 2-ASK
iv) 4-ASK
b) A typical telephone line allows frequencies from 300 to 3300 Hz, and is to be used for digital data transmission.
i) Find the maximum practical data rate that the line can support, given a signal-to-noise ratio of 30 dB.
ii) Discuss the implications of this, using no more than 200 words.
c) How much channel bandwidth is required to frequency-division multiplex 5 user channels, each of bandwidth 8 kHz, with 1.5 kHz guard bands between channels, using :
i) SSB
ii) DSB
iii) FM, with β= 8
d) An audio (speech) signal is to be sampled and quantised prior to live digital transmission. The maximum data rate supported by the channel is 130 kbps, and the available sampling rates and bit depths are as follows:
Sampling rates: 8, 11, 22, 44, 88 and 96 kHz
Bit depths: 2, 4, 8, 16, 24 and 32 bits
Select the digitisation settings that would result in the highest quality reproduction of the message at the receiver, justifying your choice.
Total 25
