COMP3308/3608 Artificial Intelligence

Week 9 Tutorial exercises

Multilayer Neural Networks 2. Deep Learning.

Exercise 2.

a) Given is a 2-layer feed-forward neural network with 10 input units, 5 hidden units and 3 output units. How many weights does it contain? Don’t forget to include the bias weights.

Answer:

weights: 10*5 + 5*3 = 65

biases: 5*1 + 3*1=8

total: 65+8 = 73

b) Is the backpropagation algorithm guaranteed to achieve 100% correct classification for any linearly- separable set of training examples, given a sufficiently small learning rate? Explain briefly.

Answer: No, it will iterate until a local minimum of the error is reached.

Exercise 3. Cybenko’s theorem (slide 39) states that any continuous function can be approximated by a backpropagation network with 1 hidden layer. Why do we use networks with more than 1 hidden layer?

Answer: This is an existence theorem, i.e. it says that there is a network with 1 hidden layer that can do this (and doesn’t tell us how to find this network). However, the theorem doesn’t say that a network with 1 hidden layer is optimum in the sense of training time, ease of implementation, or (more importantly) generalization ability (i.e. ability to classify correctly new examples).

Exercise 4. Using Weka

1. Load the iris data (iris.arff). Choose  10-fold cross validation. Run the Naïve Bayes and Multilayer percepton (trained with the backpropagation algorithm) classifiers with the default parameters and compare

their performance. Note that multilayer perceptron in Weka is under “Functions” .

Which classifier was more accurate? Which one was faster to train?

2. Select “MultilayerPerceptron” as a classifier. In the pane “Choose” (where “MultilayerPerceptron” should appear click to open the options window. If you click “More” you can learn what each of them means. What does “a” in the number of hidden layers mean? Experiment with 1 hidden layer and different number of neurons in it. As you can see the classification performance of the backpropagation network is very sensitive to the architecture. Choose “GUI=true” from the window with the options to visualize the different networks.

Exercises using Matlab and Matlab’s Neural Network demos

Exercise 5. Convergence with different learning rates

In Matlab, type nnd12sd2 to run the demo.

Try different starting positions and different learning rates. What is the influence of the learning rate? What happens if the learning rate is too big or too small?

Answer: The learning rate determines the speed of the training; too big – faster training but oscillations, and overshooting of the minimum; too small – slow convergence

Exercise 6. Backpropagation with momentum

In Matlab, type nnd12mo to run the demo.

Experiment with different values for the momentum and learning rate. What is the advantage of using a momentum?

Answer: Speeds up learning by allowing to use a larger learning rate while maintaining the stability.

Exercise 7. Generalization

In Matlab, type nnd11gn to run the demo.

Try a simple function (i.e. choose a small difficulty index) with too many hidden neurons. What is the

reason for the poor generalization?

Answer: Overtraining (overfitting).

Exercise 8. Convolution in deep NNs

Follow the convolution example on this website to see how the convolved features are computed:

http://deeplearning.stanford.edu/tutorial/supervised/FeatureExtractionUsingConvolution/

Exercise 9. Backpropagation example

Follow the backpropagation walkthrough example prepared by Josh Stretton and available from Canvas; it is an extended version of the example from the first lecture on slides 33-37. The goal is to understand the forward and backward passes of the backpropagation algorithm and how the weights are updated.
