ECE 434-579, Spring 2023

Project 1: LINUX OS, Processes and Inter Process Communication

Issue Date: Sunday 03-05-2023, Due Date: Wed March 23th 2022, 8.00pm

Total Points (20 + 12 = 32 points)

Very useful resources for writing C code:

https://www.tutorialspoint.com/cprogramming/c_command_line_arguments.htm https://www.cprogramming.com/tutorial/c-tutorial.html

Programming Language: by Brian W. Kerninghan, Dennis M.Ritchie

Problem 1: Introduction to multi-process environments and IPC (20 points)

Problem Introduction and Description: Generate a text file and populate it with L (>=10,000) positive integers, randomly generated. Identify the MAXIMUM, the AVERAGE, and a number of “H”<20 GIVEN HIDDEN KEY INTEGERs out of the 50 hidden keys randomly placed in the file. Use Inter Process Communication (IPC) of pipes (or shared memory – if you are familiar with it) to partition the file/array into chunks and distribute work to more than one processes.

You must “hide” your secret keys into your list/file of > = 10,000 integers. The hidden keys will be 50 negative integers (with value - 1) inserted at random positions into your file. But then, after creation of the file, you “forget” where the hidden keys are located. You only know that you must look for “H” secret keys.

Arguments/Parameters: Arguments: L, H, and Process Number (PN) are provided at run time and are handled by main (int argc, char* argv[]).You can also request this information from the keyboard and have your program read/scanf the information entered from the user. (how to use argc-argv[] -- read the related section on tutorialspoint site provided above).

Experiments Set Up: Use multiple processes from 1 to “PN” (where PN: Process Number argument) in the following layout strategies:

1)) A DFS tree (a chain of processes) – can experiment using 1 up to the max. no of processes you can generate before you get a core dump message.

2)) A BFS tree with a) 2, b) 3, and c) 4 children. Can experiment using as PN the max. no of processes you can generate before you get a core dump message.

Every time a process forks a child or children process(es), the parent must pass to the offspring the part of the partitioned file that corresponds to each offspring. This information can be passed through pipes. Then each offspring processes its own part/segment of the array/file to identify the local metrics of interest and also forks (if needed) its own offspring and passes on to their offspring their corresponding array/file segments (the array/segment for the corresponding sub-tree). Any process that has forked child/children must invoke waitpid for all its direct offspring and analyze how they have been interrupted/terminated. Once a child identifies its local max. and avg, it must send this data to its parent. The parent must collect all metrics of interest from all children, process these accordingly, and when ready, send its own calculation results to its own parent, and so on and so forth until the root is reached, and the final metrics that show the total maximum and total average are computed.

The internal process awaits of the termination of all its children processes. Every process prints a corresponding message every time it transitions to another phase (for example: start, loop to wait for children termination, computation of its local max and avg., allowing its own termination), so that the validation of the correct program operation is feasible.

IMPORTANT on PROCESSES RETURN VALUES: In order to separate the processes, please

make sure that every process has the potential to terminate with a different return code if/when it calls exit. When there are many processes in a BFS layout, you must find an algorithm that ensures internal nodes communicate unique return codes to their children, that do not class with the return codes of the children from other parents (hint for one possible scenario:

research on the properties of the BFS trees: level and number of nodes in each level).

In an example, one scenario can be:

A = 2, B = 4, C = 6, D = 10.

Here the return codes are distributed arbitrarily, the tree nodes are very few and hence the return codes do not class. But what happens when we have a tree with many more nodes?

Part 1: (20 pts)

Implement all the above as described, implementing the correct system calls with the correct status manipulation and options (as provided in the corresponding skeleton program). Also, invoke system call pstree from the root with the corresponding flags, at intervals you find important. Inspect the process tree, and check if this is correct.

You must identify the trade-offs in computation versus communication overhead when you fork multiple process from a single process. The results of this experiment will help you understand if multiple process that partition the large array help you calculate the requested values faster. Remark: Record the time it takes for each of the programs to run and comment on your observations. Try it on lists of size L: 10k, 100k, 1M, 5M.

Hint: You should first load the file into an array then start working on the data. Input Format: Input will be in a text file.

Output Format: You should print out the results in a text file. Every process that is created should print out their own process id and their parent’s process id. Then once you have computed the final max, avg, and hidden keys, you will print those out. Please follow this format:

Hi I’m process 2103 with return arg 2 and my parent is 2102 .

Hi I’m process 2104 with return arg 3 and my parent is 2103.

Hi I’m process 2105 with return arg 4 and my parent is 2104.

Max=50, Avg =36 (fictitious numbers).

Hi I’m process 2103 with return arg 2. I found the hidden key in position A[65].

Hi I am process 2108 with return arg 7 and I found the hidden key in position A[123].

Hi I am process 2014 with return arg 13 and I found the hidden key in position A[204]. Hi I am process … . (all the above are fictitious numbers).

Find which process layout completes faster and how many processes are involved. Modify the number of elements (the size of the array) and check if and how this may affect your results. Provide your insight on your findings. Is this what you expected, yes, no, and why yes/no?

Summary:

1) Write a program to solve the problem using only one process.

2) Write a program to solve the problem using multiple processes where each process spawns at most one process. (Like DFS). The maximum number of processes spawned should be NP.

3) Write a program to solve the problem using multiple processes where the first process spawns a fixed number of processes, (2 or 3 or 4), and the children spawn their own (2 or 3 or 4) multiple processes each, and so on and so forth. The maximum number of processes spawned should be NP. Your tree structure may be pre-defined and hence avoid using loops or recursion or counters to create a new tree. You also have the option to ask the user to provide the size of chidren (1, 2, 3, 4). At the end, you must produce the structures, address all questions, and compare the results for each structure.

4) Your ultimate goal should be to find the process tree that produces the final result faster. Can you fine-tune the size of variable NP to do that? Consider lists of increasing sizes. There is a trade-off w.r.t. to the number of processes but there is also a trade-off w.r.t. the number of integers in the file (and increasing file sizes). What are the trade-offs you observe here?

5) Can you create an arbitrary number of processes or are there any limitations? If you find limitations in your version of Linux OS, please show (e.g. via a printscreen or a file) what are your exact limitations in increasing the number of processes you will be generating. Why is this so?

6) What is the maximum number of processes you can create before your system crashes?

Part 2: (12 pts)

Once you have completed Part 1, now add the following features to your design: For part 2 you must add to the includes of your program the following: # include signal.h

Once a child process has calculated its metrics of interest and has sent these to its parent, then it will “pause” , waiting for its parent to decide on its fate.

Pause should be implemented by having the process send signal SIGTSTP to itself, using the following system call:

- raise(SIGTSTP);

Pausing the child as above, will give time to the parent to decide what to do with the given child.

The child must separately notify the parent how many hidden elements it has. The parent will make decisions about the fate of the child based on the number of hidden nodes.

Every parent updates now its own hidden nodes by adding to its existing hidden nodes only the first hidden node of every child (if there is any).

For example if child pid gives 5 hidden nodes to the parent ppid, parent ppid makes is decision for child pid based on the 5 hidden nodes, but for its own subsequent computations adds only +1 (hidden nodes) coming from this child, to the number of hidden nodes it already has. So, if the parent has 4 children, and all children are polluted with 20 hidden nodes in total, the parent will add to itself exactly 4 hidden nodes and no more.

Decision rules for a child with pid and parent with ppid:

1) IF localMAX(child) > localMAX(parent) or if localMAX(child) > localMAXs of all sibling, the parent wants to keep the related branch around for longer, so it will send this child a signal to CONTINUE, no matter if the child also has >=H hidden nodes. This will be done via system call:

signal(child, SIGCONT);

The child will invoke system call: sleep(100); so that it gives the system the opportunity to display the subtree of interest, invoking pstree from the root .*** (there can be variations here … but we must dig deeper into signals … . Will do for the following project).

2) ELSE IF If the above do not hold and If child with has hidden numbers >=H then this child will be terminated, by having the parent send a SIGKILL signal to this child, invoking the following system call:

signal(child,9); or signal(child,SIGKILL)

You must check what the case is with the offspring of a terminated child. Are they also terminated at this point (cascaded termination) or are they adopted by init? One way to look into this is call ps –au from another terminal and observe the status of processes: running, schedule, blocked, zombie, terminated, … . (please research into this).

3) If the above two rules do not hold, then the parent will unblock the child by invoking signal(pid, SIGCONT);

and allow them to run their remaining code and exit naturally, by having the children invoke exit(child_arg); at the end of their code. Before that, the child should invoke system call sleep(20); so that it gives the system the opportunity to display the subtree of interest calling pstree from the root.

Reminder: The arg that must be used with the exit system call has been passed by the parent through the pipe, and must be unique for every child in the process.

Objective: You must show how you have implemented all the above design requirements and you must prove that the system behaves as prescribed. The processes that you generate must remain active for some considerable window of time in order for the user to be able to observe the tree. Either the leaf process or all processes execute a call to: sleep(). The internal process awaits of the termination of all its children processes and analyze the termination circumstances with the proper printouts, using the unique return ids of the processes and using system calls

such as pstree to display the tree.

Additional Questions:

1. What happens if root process A is terminated prematurely, by issuing: kill -SIGKILL ?

2. What happens if you display the process tree with root pstree(getpid()) instead of pstree(pid()) in main()? Which other processes appear in the tree and why?

Solution:

What to turn in:

C files for each problem

A makefile in order to run your programs.

Input text file (your test case)

Output text file (for your test case)

Report: Explain design decisions (fewer vs. more processes, process structure, etc.).

Elaborate on what you have learned from each problem. Answer the question(s) below each part/subproblem. Also, please consider providing a very detailed report, as along with your C file deliverables, it corresponds to a substantial portion of your grade.
